UPS Single-Phase Pure Sine Wave UPS Battery Uninterruptible Power Supply High-Frequency 1kVA 3kVA 6kVA UPS Minimum Conversion Voltage: 160VAC/140VAC/120VAC/110V

ModelWall-mounted typeVertical type6KVA10KVA6KVA1OKVACapacity6KW10KW6KW10KWIn putVoltage RangeMinimum switching voltageAt 50% load, 11OVAC z3%; at 100% load, 176VAC13%Minimum recovery voltageMinimum switching voltage +10VMaximum switching voltage300VAC*3 %Maximum recovery voltageMaximum switching vo......Keywords:UPS Single-Phase Pure Sine Wave UPS Battery Uninterruptible Power Supply High-Frequency 1kVA 3kVA 6kVA UPS Minimum Conversion Voltage: 160VAC/140VAC/120VAC/110V, UPS, 10ah

Send Inquiry

Product Description

Model		Wall-mounted type		Vertical type
		6KVA	10KVA	6KVA	1OKVA
Capacity		6KW	10KW	6KW	10KW
In put
Voltage Range	Minimum switching voltage	At 50% load, 11OVAC z3%; at 100% load, 176VAC13%
	Minimum recovery voltage	Minimum switching voltage +10V
	Maximum switching voltage	300VAC*3 %
	Maximum recovery voltage	Maximum switching voltage -10V
Frequency Range		40-60HZ@50HZ system/50-70HZ@60HZ system
Phase		L+ N+PE
Power Factor		100% load*0.99
Output
Output Voltage		208/220/230/240VAC
Output Voltage Accuracy		*1%
Frequency Range (synchronization range)		40-60hz@50HZsystemI50-70HZ@60HZsystem
Frequency Range (battery mode)		50hz0.1HZor60HZ0.1HZ
Overload	AC Mode	30min@102%-110%Ioad, 10min@110%-130%load 30s@130%-150%Ioad, 500ms@ >150%Ioad
	Battery Mode	10min@102%-110%Ioad, 1min@110%-130%Ioad 10s@130%-150%Ioad, 500ms@ >150%Ioad
Current peak ratio		3:1 (Maximum)
Harmonic distortion		S2% ( linear load ) , 5%(non-linear load)
Switching time	Mains Battery	Oms
	Inverter Bypass	Oms
Effectiveness
AC Mode		95%
Battery Mode		94.8% (20pcs batteries)
Battery
Standard	Battery Number	12-16 pcs	16 pcs	12-16 pcs	16 pcs
	Charging Current	default 1A
	Charging Voltage	13.65 x NI-1%
Long Run	Battery Number	16 -20 pcs
	Charging Current	Preset: 6A-L 10%, 1-12A optional
	Charging Voltage	13.65 x N+1%
Apperance
Standard	Size Long•Width•High(mm)	38043888 (Battery pack size: 496a438 130)		384"190*730
Long Run	Size Long Width High(mm)	380"438*88		384"190*335
Environment
Operating Temperature		0 - 40°C
Operating Moisture		< 95% And no condensation
Operating Altitude		< 1000m"*
Noise		less than 50dB@1 Meter
Management
Sm artRS-232		Support Windows@2000/2003/XP/Vista/2008. Windows@7/8. Linux. Unix and MAC
0 ptional SNMP		Support for power management by SNMP administrator and web browser.
